Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Appendix 0:
Status model
DMM7510-901-01 Rev. B / May 2015 3
Standard Event Register
The Standard Event Register set includes two 8-bit registers:
• Standard Event Status Register: Reports when a predefined event has occurred. The register
latches the event and the corresponding bit remains set until it is cleared by a read.
• Standard Event Status Enable Register: You can enable or disable bits in this register. This
allows the predefined event (from the Standard Event Status Register) to set the ESB of the
Status Byte Register.
Figure 173: Model DMM7510 Standard Event Register

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
