Keithley DMM7510 Reference Manual

Section
8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
8-274 DMM7510-901-01 Rev. B / May 2015
trigger.lanin[N].clear()
This function clears the event detector for a LAN trigger.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
trigger.lanin[N].clear()
N
The LAN event number (1 to 8) to clear
Details
The trigger event detector enters the detected state when an event is detected. This function clears a
trigger event detector and discards the previous of the trigger packet.
This function clears all overruns associated with this LAN trigger.
Example
trigger.lanin[5].clear()
Clears the event detector with LAN event trigger 5.
Also see
trigger.lanin[N].overrun (on page 8-275)
trigger.lanin[N].edge
This attribute sets the trigger operation and detection mode of the specified LAN event.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Restore configuration
Instrument reset
Power cycle
Configuration script
trigger.EDGE_EITHER
Usage
edgeMode = trigger.lanin[N].edge
trigger.lanin[N].edge = edgeMode
edgeMode
The trigger mode; see the Details for more information
N
The LAN event number (1 to 8)
Details
This command controls how the trigger event detector and the output trigger generator operate on the
given trigger. These settings are intended to provide behavior similar to the digital I/O triggers.
LAN trigger mode values
Mode Trigger packets detected as input LAN trigger packet generated
for output with a…
trigger.EDGE_EITHER
Rising or falling edge (positive or
negative state)
negative state
trigger.EDGE_FALLING
Falling edge (negative state)
negative state
trigger.EDGE_RISING
Rising edge (positive state)
positive state

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
