Keithley DMM7510 Reference Manual

Section
7: Introduction to TSP commands Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
7-34 DMM7510-901-01 Rev. B / May 2015
Connecting an instrument in TSB
You must use the TSP command set with the Test Script Builder software. For information on
changing the command set, refer to Determining the command set you will use (on page 2-89
).
To connect the Test Script Builder software to an instrument:
1. Click the Open Instrument icon in the script editor toolbar.
Figure 152: Opening an instrument connection in TSB
2. The Select Instrument dialog box opens. Select an existing instrument from the list, or type the
VISA resource ID of the instrument in the Select or enter new instrument box.
3. If needed, enter a password.
Figure 153: Select Instrument dialog box

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
