Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 1:
Introduction
DMM7510-901-01 Rev. B / May 2015 1-3
• Common commands: Contains descriptions of IEEE Std. 488.2 common commands.
• Status model: Describes the Model DMM7510 status model.
The PDF version of this manual contains bookmarks for each section. The manual sections are also
listed in the Table of Contents at the beginning of this manual.
For more information about bookmarks, see Adobe
®
Acrobat
®
or Reader
®
help.
Capabilities and features
The Model DMM7510 has the following features:
• High-resolution, five-inch touchscreen display with enhanced graphical data visualization and
on-screen debug and error histories
• Ability to perform sensitive measurements on low-level signals
• Simplified trigger model with measure configuration lists
• Front-panel USB-A connector for flash-drive support; rear-panel USB-B connector for
communication, control, and data transfer
Some additional capabilities of the Model DMM7510:
• Limit testing with a built-in comparator for pass/fail testing
• Digital I/O for stand-alone binning operations or interface to a component handler
• SCPI and Test Script Processor (TSP
TM
) programming languages with remote interface ports
(IEEE-488/GPIB, USB, and LAN)
• Built-in math expressions and user-defined expressions (using a remote interface)
• Filtering to reduce reading noise
• Trigger model supports extensive triggering and synchronization schemes at hardware speeds
• LXI
®
Core Specification 1.4 compliance
• TSP-Link
®
system expansion interface that test system builders can use to connect multiple
instruments in a master and subordinate configuration.
• Supports IEEE-488 (GPIB), USB, and ethernet local area network (LAN) connections
General ratings
The Model DMM7510 instrument's general ratings and connections are listed in the following table.
Category Specification
Supply voltage range
100 V
RMS
to 240 V
RMS
, 50 Hz or 60 Hz (autosensing at power on)
Input and output connections
See Rear panel overview.
Environmental conditions For indoor use only
Altitude: Maximum 2000 meters (6562 feet) above sea level
Operating: 0 °C to 50 °C (32 °F to 122 °F), ≤80 % relative humidity at
35 °C (95 °F)
Storage: −30 °C to 70 °C (−22 °F to 158 °F)
Pollution degree: 1 or 2

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
