Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 6:
SCPI command reference
DMM7510-901-01 Rev. B / May 2015 6-211
:TRIGger:EXTernal:OUT:LOGic
This command sets the output logic of the trigger event generator to positive or negative for the external out line.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings
NEG
Usage
:TRIGger:EXTernal:OUT:LOGic <logicType>
:TRIGger:EXTernal:OUT:LOGic?
<logicType>
The output logic of the trigger generator:
• Assert a TTL-high pulse for output: POSitive
• Assert a TTL-low pulse for output:
NEGative
Details
This command sets the trigger event generator to assert a TTL pulse for output logic. Positive is a
high pulse; negative is a low pulse.
Example
*RST
:TRIG:EXT:IN:CLE
:TRIG:EXT:OUT:LOG NEG
:TRIG:EXT:OUT:STIM EXT
:TRIG:EXT:IN:EDGE FALL
Reset the external I/O port values to their
defaults.
Clear any event triggers on the external in
line.
Set the output logic to negative (it asserts a
low pulse).
Set the stimulus to the external input.
Set the external input to detect a falling
edge.
Also see
None

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
