6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
6-112 DMM7510-901-01 Rev. B / May 2015
[:SENSe[1]]:<function>:TRANsducer
This command sets the transducer type.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
TCouple
Usage
[:SENSe[1]]:<function>:TRANsducer <type>
[:SENSe[1]]:<function>:TRANsducer?
<function>
The function to which the setting applies; see Functions
<type>
The type of transducer:
• Thermocouple: TCouple
• Thermistor: THERmistor
• 3-wire RTD: TRTD
• 4-wire RTD:
FRTD
Functions
VOLTage[:DC]
RESistance
TEMPerature
VOLTage[:DC]:RATio
VOLTage:AC
FRESistance
CONTinuity
DIGitize:VOLTage
CURRent[:DC]
DIODe
FREQuency[:VOLTage]
DIGitize:CURRent
CURRent:AC
CAPacitance
PERiod[:VOLTage]
Details
The transducer type determines the type of temperature measurement that is made. Each transducer
type has related settings that must also be set. For example, thermocouple measurements are only
made if the type is set is set to thermocouple. You also need to set the thermocouple type when
setting up a thermocouple. For a transducer type of four-wire RTD, you also set the RTD type.
Example
:FUNC "TEMP"
:TEMP:TRANsducer FRTD
:TEMP:RTD:FOUR PT3916
Set the measure function to temperature.
Set the transducer type to 4-wire RTD.
Set the RTD type to PT3916 for 4-wire RTDs.
Also see
[:SENSe[1]]:<function>:RTD:FOUR (on page 6-100)
[:SENSe[1]]:<function>:RTD:THRee (on page 6-101)
[:SENSe[1]]:<function>:TCouple:TYPE (on page 6-107)
[:SENSe[1]]:<function>:THERmistor (on page 6-108)
Temperature measurements (on page 2-120)
