Keithley DMM7510

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 6:
SCPI command reference
DMM7510-901-01 Rev. B / May 2015 6-225
:TRIGger:LOAD "Keithley2001"
This command loads a predefined trigger model configuration that emulates a Keithley Instruments 2001 trigger
model.
Type Affected by Where saved Default value
Command only
Not applicable
Not applicable
Not applicable
Usage
:TRIGger:LOAD "Keithley2001", <arm1Bypass>, <arm1Source>, <arm1Count>,
<arm2Bypass>, <arm2Source>, <arm2Count>, <arm2Delay>, <trigBypass>,
<trigSource>, <trigCount>, <trigDelay>
<arm1Bypass>
Bypass Arm 1:
ON
(
1
)
Do not bypass Arm 1: OFF (0)
<arm1Source>
The event that triggers Arm 1; see Details
<arm1Count>
The number of times to repeat Arm 1
<arm2Bypass>
Bypass Arm 2: ON
Do not bypass Arm 2: OFF
<arm2Source>
The event that triggers Arm 2; see Details
<arm2Count>
The number of times of times to repeat Arm 2
<arm2Delay>
The delay time before each measurement (167 ns to 10 ks); default is 0 for
no delay
<trigBypass>
Bypass the trigger layer: ON
Do not bypass the trigger layer:
OFF
<trigSource>
The event that triggers the trigger layer; see Details
<trigCount>
The number of times to repeat the trigger layer
<trigDelay>
The delay time before each measurement (167 ns to 10 ks); default is 0 for
no delay
