Keithley DMM7510 Reference Manual

Section
6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
6-226 DMM7510-901-01 Rev. B / May 2015
Details
If the trigger layer is not bypassed, the External In/Out terminal is asserted. The arm layers do not
assert the external in/out terminal.
You can use this template to emulate other trigger models if you use only one of the arm layers. Set
the other arm layers to a source of NONE, a count of 1 and a delay of 0.
The out line of the EXT TRIG IN/OUT rear-panel terminal is asserted at the end of each
measurement.
Trigger events
Event description Event constant
No trigger (immediate)
NONE
Front-panel TRIGGER key press (manual trigger)
DISPlay
Notify trigger block <n> (1 to 8) generates a trigger event when
the trigger model executes it
NOTify<n>
A command interface trigger (bus trigger):
• Any remote interface: *TRG
• GPIB only: GET bus command
• VXI-11: VXI-11 command
device_trigger
COMMand
Line edge (either rising, falling, or either based on the
configuration of the line) detected on digital input line <n> (1 to 6)
DIGio<n>
External in trigger
EXTernal
Example
Refer to the application notes for the Model DMM7510 on the Keithley Instruments website
http://www.keithley.com for an example with additional detail about this command.
Also see
None

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
