Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 6:
SCPI command reference
DMM7510-901-01 Rev. B / May 2015 6-191
:TRIGger:BLOCk:BUFFer:CLEar
This command defines a trigger model block that clears the reading buffer.
Type Affected by Where saved Default value
Command only
Recall settings
Instrument reset
Power cycle
Save settings
Not applicable
Usage
:TRIGger:BLOCk:BUFFer:CLEar <blockNumber>
:TRIGger:BLOCk:BUFFer:CLEar <blockNumber>, "<bufferName>"
<blockNumber>
The sequence of the block in the trigger model
<bufferName>
The name of the buffer, which must be an existing buffer; if no buffer is
defined, defbuffer1 is used
Details
When trigger model execution reaches the buffer clear trigger block, the instrument empties the
specified reading buffer. The specified buffer can be the default buffer or a buffer that you defined.
If you are clearing a user-defined reading buffer, you must create the buffer before you define this
block.
Example
TRIG:LOAD "EMPTY"
TRIG:BLOC:BUFF:CLE 1
TRIG:BLOC:MEAS 2
TRIG:BLOC:BRAN:COUN 3, 5, 2
TRIG:BLOC:DEL:CONS 4, 1
TRIG:BLOC:BRAN:COUN 5, 3, 2
Reset trigger model settings.
Clear defbuffer1 at the beginning of the
trigger model.
Loop and take 5 readings.
Delay 1 s.
Loop three more times back to block 2.
At end of execution, 15 readings are stored in
defbuffer1.
Also see
Buffer clear block (on page 3-80)
:TRACe:MAKE (on page 6-160)
:TRIGger:BLOCk:CONFig:NEXT
This command recalls the settings at the next index of a configuration list.
Type Affected by Where saved Default value
Command only
Recall settings
Instrument reset
Power cycle
Save settings Not applicable
Usage
:TRIGger:BLOCk:CONFig:NEXT <blockNumber>, "<configurationList>"
<blockNumber>
The sequence of the block in the trigger model
<configurationList>
The configuration list from which to recall settings

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
