el DMM7510 7½ Digit Graphical Sampling Multimeter Reference Manual Appendix 0:
Common commands
DMM7510-901-01 Rev. B / May 2015 3
The instrument returns a decimal value that corresponds to the binary-weighted sum of all bits set in
the register.
Bit
Decimal
value
Constant When set, indicates the following has occurred:
0
1
status.standard.OPC
All pending selected instrument operations are
complete and the instrument is ready to accept new
commands. The bit is set in response to an
*OPC
(on page 6) command or TSP opc() (on page 8-230)
function.
1
2
Not used
Not used.
2
4
status.standard.QYE
Attempt to read data from an empty Output Queue.
3
8
Not used
Not used.
4
16
Not used
Not used.
5
32
Not used
Not used.
6
64
Not used
Not used.
7
128
status.standard.PON
The instrument has been turned off and turned back
on since the last time this register was read.
Command errors include:
• IEEE Std 488.2 syntax error: The instrument received a message that does not follow the defined
syntax of the IEEE Std 488.2 standard.
• Semantic error: The instrument received a command that was misspelled or received an optional IEEE
Std 488.2 command that is not implemented in the instrument.
• GET error: The instrument received a Group Execute Trigger (GET) inside a program message.
Constants are only available if you are using the TSP command set. If you are using the SCPI
command set, you must use the decimal values.
Example
*ESE 129
*ESE 129 sets the Status Enable register of the Standard Event
Register to binary
10000001
, which enables the PON and OPC bits.
Also see
*CLS (on page 2)
Standard Event Register (on page 3)
Status model (on page 1)
