7½ Digit Graphical Sampling Multimeter Reference Manual Section 2:
DMM7510-901-01 Rev. B / May 2015 2-87
The Model DMM7510 only allows fewer than three clients to open the virtual front panel web page at
the same time. Only the first successfully connected client can operate the instrument. Other clients
can only view the virtual front panel.
Change the date and time through the web interface
You can change the instrument date and time through the web interface. This is the same as
changing the date and time through the front panel System Settings menu. The date and time is used
for the event log entries and data timestamps.
To change the date and time:
1. From the web interface page, select Admin.
2. In the Local time table, change the information as needed.
3. Click Submit.
Change the password through the web interface
You can change the instrument password from the web interface.
The default user name and password is admin. Note that you cannot change the user name; it
remains at admin even if the password has changed.
To change the password:
1. From the web interface Home page, select Admin.
2. In the Current password box, enter the presently used password.
3. In the New password and Confirm new password boxes, enter the new password.
4. Click Submit.
Send commands using the web interface
You can send individual commands using the web interface.
The active command set is listed above the Command box.
To send commands using the web page:
1. From the navigation bar on the left, click Send Commands.
2. If requested, log in.
3. In the Command box, enter the command.
4. Click Send Command to send the command to the instrument. The command is displayed in the
Command Output box. If there is a response to the command, it is displayed after the command.
5. To view any events that have occurred, click Return Error.
6. To clear the Command Output list, click Clear Output.
