The instrument clears the memory of the recorded event when the trigger model exits the wait block.
It also clears the recorded trigger event when the clear parameter is set to enter.
All items in the list are subject to the same action — you cannot combine AND and OR logic in a single
wait block.
When you select the Wait block, the following options are available.
Setting Description
Event 1
An event that must occur before the trigger block will continue.
Event Logic
Optional. Determines if all of the defined events must occur or if at
least one of the events must occur.
Select AND if all of the defined event must occur.
Select OR if at least one of the event must occur.
Event 2
Optional. An event that must occur before the trigger block will
continue.
Event 3
Optional. An event that must occur before the trigger block will
continue.
Clear
To clear previously detected trigger events when entering the wait
block, select Enter.
To immediately act on any previously detected triggers and not
clear them, select
Never
.

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
