On event block
The branch-on-event block branches to a specified block when a specified trigger event occurs. If the
trigger event has not yet occurred when trigger model execution reaches the branch-on-event block,
the trigger model continues to execute the blocks in the normal sequence. After the trigger event
occurs, the next time trigger model execution reaches the branch-on-event block, it goes to the
branching block.
Trigger events are reset when the trigger model is at the start block, so only events that occur after
you start trigger model execution are detected by the branch-on-event block. The event is also reset
after trigger model execution completes the branching block.
When you select the branch-on-event block, the following options are available.
Setting Description
Event
The event that causes this block to branch
Branch to Block
The block number to execute when the specified event occurs
The event can be any of the events described in the following table.
Event Description
Digital Input
Line edge detected on a digital input line. When you select this
option, you will also select the digital input to monitor.
After selecting the digital input line, press Config to select the type
of edge (falling, rising, or either).
TSP-Link Input
Line edge detected on a TSP-Link synchronization line. When you
select this option, you will also select the TSP-Link line to monitor.
After selecting the TSP-Link line, press Config to select the type of
edge (falling, rising, or either).
Timer
A trigger timer expired. When you select this option, you will also
select the timer to monitor.
After selecting the timer, press Config to select the delay time,
count, or start time.
Command
A command interface trigger (bus trigger):
• Any remote interface: *TRG
• GPIB only: GET bus command
• VXI-11: VXI-11 command
device_trigger
Display TRIGGER
Key
Front-panel TRIGGER key press.
External In Trigger
Use a pulse from the external I/O. When you select this option,
press Config to select the type of edge (falling, rising, or either).
Analog Trigger
Use the analog trigger.
LAN In Trigger
A LXI trigger packet is received on LAN trigger object. When you
select this option, you will also select the LAN trigger to monitor.
After you select the line, press Config to select the type of edge
(falling, rising, or either).
Blender
Wait for the events set by an event blender.
None
No trigger event. The trigger model will not run if the wait event is
set to none.
For information on trigger events, see Using trigger events to start actions in the trigger model (on
page 3-99).

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
