Section
6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
6-46 DMM7510-901-01 Rev. B / May 2015
:DISPlay:SCReen
This command changes which front-panel screen is displayed.
Type Affected by Where saved Default value
Command only Not applicable Not applicable Not applicable
Usage
:DISPlay:SCReen <screenName>
<screenName>
The screen to display:
Home screen: HOME
Home screen with large readings: HOME_LARGe_reading
Reading table: READing_table
Graph screen (opens last selected tab): GRAPh
Histogram screen: HISTogram
FUNCTIONS swipe screen: SWIPE_FUNCtions
GRAPH swipe screen: SWIPE_GRAPh
SECONDARY swipe screen: SWIPE_SECondary
SETTINGS swipe screen: SWIPE_SETTings
STATISTICS swipe screen: SWIPE_STATistics
USER swipe screen: SWIPE_USER
Example
DISP:CLE
DISP:SCR SWIPE_USER
DISP:USER1:TEXT "Batch A122"
DISP:USER2:TEXT "Test running"
Clear and display the USER swipe screen.
Set the first line to read "Batch A122" and
the second line to display "Test running".
Also see
None
