Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 6:
SCPI command reference
DMM7510-901-01 Rev. B / May 2015 6-91
The following table lists the ranges for each function.
If the measurement function is… The available ranges are…
DC voltage
100 mV, 1 V, 10 V, 100 V, 1000 V
AC voltage
100 mV, 1 V, 10 V, 100 V, 700 V
DC current
10 µA, 100 µA, 1 mA, 10 mA, 100 mA, 1 A, 3 A
10 A available for rear terminals
AC current
1 mA, 10 mA, 100 mA, 1 A, 3 A
10 A available for rear terminals
2-wire resistance
10 Ω, 100 Ω, 1 kΩ, 10 kΩ, 100 kΩ, 1 MΩ, 10 MΩ, 100 MΩ, 1 GΩ
4-wire resistance
1 Ω, 10 Ω, 100 Ω, 1 kΩ, 10 kΩ, 100 kΩ, 1 MΩ, 10 MΩ, 100 MΩ, 1 GΩ
Continuity
1 kΩ (fixed)
Diode 10 V (fixed)
Capacitance
1 nF, 10 nF, 100 nF, 1 µF, 10 µF, 100 µF, 1 mF
DC voltage ratio
100 mV, 1 V, 10 V, 100 V, 1000 V
Digitize voltage
100 mV, 1 V, 10 V, 100 V, 1000 V
Digitize current
10 µA, 100 µA, 1 mA, 10 mA, 100 mA, 1 A, 3 A
10 A available for rear terminals
Example 1
:SENS:CURR:RANG 10E-6
Select the 10
µ
A range.
Example 2
:DIG:CURR:RANG 10E-6
Select the 10
µ
A range.
Example 3
:DIG:VOLT:RANG 50e-3
Select the 100 mV range.
Also see
Ranges (on page 3-3)
[:SENSe[1]]:<function>:RANGe:AUTO (on page 6-89)

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
