6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
6-156 DMM7510-901-01 Rev. B / May 2015
The options for <bufferElements> are described in the following table.
Option Description
The date when the data point was measured; not available for reading buffers that
are set to the style compact
Returns an additional value (such as the sense voltage from a DC voltage ratio
measurement); the reading buffer style must be set to full to use this option
The measured value as it appears on the front panel
The fractional seconds when the data point was measured
The relative time when the data point was measured
The seconds in UTC (Coordinated Universal Time) format when the data point was
measured
The status information associated with the measurement; see the "Buffer status bits
for sense measurements" table below
The time when the data point was measured
The timestamp when the data point was measured
The unit of measure of the measurement
The STATus buffer element returns status values for the readings in the buffer. The status values are
floating-point numbers that encode the status value. Refer to the following table for values.
Buffer status bits for sense measurements
Bit (hex) Name Decimal Description
Measure status questionable
A/D converter from which reading originated; for the
Model DMM7510, this will always be 0 (Main) or 2
Measure terminal, front is 1, rear is 0
Measure status limit 2 low
Measure status limit 2 high
Measure status limit 1 low
Measure status limit 1 high
