Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 6:
SCPI command reference
DMM7510-901-01 Rev. B / May 2015 6-183
:TRIGger:BLOCk:BRANch:COUNter:COUNt?
This command returns the count that the trigger model is on.
Type Affected by Where saved Default value
Query only
Recall settings
Instrument reset
Power cycle
Not applicable
Not applicable
Usage
:TRIGger:BLOCk:BRANch:COUNter:COUNt? <blockNumber>
<blockNumber>
The sequence of the block in the trigger model
Details
The query returns the number of times the trigger model has looped. The counter is defined by
:TRIGger:BLOCk:BRANch:COUNter.
Example
TRIG:LOAD "Empty"
TRIG:BLOC:BUFF:CLEAR 1
TRIG:BLOC:MEAS 2
TRIG:BLOC:BRAN:COUN 3, 5, 2
TRIG:BLOC:DEL:CONS 4, 1
TRIG:BLOC:BRAN:COUN 5, 3, 2
INIT
TRIG:BLOCK:BRAN:COUN:COUN?
Reset trigger model settings.
Clear defbuffer1 at the beginning of the
trigger model.
Loop and take 5 readings.
Delay 1 s.
Loop three more times back to block 2.
At end of execution, 15 readings are stored in
defbuffer1.
Check to see which count the trigger model has
completed.
Also see
:TRIGger:BLOCk:BRANch:COUNter (on page 6-182)
:TRIGger:BLOCk:BRANch:COUNter:RESet
This command creates a block in the trigger model that resets a branch counter to 0.
Type Affected by Where saved Default value
Command only
Recall settings
Instrument reset
Power cycle
Save settings Not applicable
Usage
:TRIGger:BLOCk:BRANch:COUNter:RESet <blockNumber>, <counter>
<blockNumber>
The sequence of the block in the trigger model
<counter>
The block number of the counter that is to be reset

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
