Keithley DMM7510 Reference Manual

Section
8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
8-176 DMM7510-901-01 Rev. B / May 2015
The following table lists the ranges for each function.
If the measurement function is… The available ranges are…
DC voltage
100 mV, 1 V, 10 V, 100 V, 1000 V
AC voltage
100 mV, 1 V, 10 V, 100 V, 700 V
DC current
10 µA, 100 µA, 1 mA, 10 mA, 100 mA, 1 A, 3 A
10 A available for rear terminals
AC current 1 mA, 10 mA, 100 mA, 1 A, 3 A
10 A available for rear terminals
2-wire resistance
10
Ω
, 100
Ω
, 1 k
Ω
, 10 k
Ω
, 100 k
Ω
,
1 M
Ω,
10 M
Ω,
100 M
Ω,
1 G
Ω
4-wire resistance with offset
compensation off and dry circuit off
1 Ω, 10 Ω, 100 Ω, 1 kΩ, 10 kΩ, 100 kΩ, 1 MΩ, 10 MΩ, 100 MΩ, 1 GΩ
4-wire resistance with offset
compensation off and dry circuit on
1 Ω, 10 Ω, 100 Ω, 1 kΩ, 10 kΩ
4-wire resistance with offset
compensation on and dry circuit off
1 Ω, 10 Ω, 100 Ω, 1 kΩ, 10 kΩ, 100 kΩ
4-wire resistance with offset
compensation on and dry circuit on
1 Ω, 10 Ω, 100 Ω, 1 kΩ, 10 kΩ
Continuity
1 kΩ (fixed)
Diode 10 V (fixed)
Capacitance
1 nF, 10 nF, 100 nF, 1 µF, 10 µF, 100 µF, 1 mF
DC voltage ratio
100 mV, 1 V, 10 V, 100 V, 1000 V
Example
dmm.measure.func = dmm.FUNC_AC_VOLTAGE
dmm.measure.range = 90
print(dmm.measure.range)
Set the range to 90 V, which selects the
100 V range.
Output:
100
Also see
dmm.digitize.range (on page 8-108)
dmm.measure.autorange (on page 8-134)

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
