Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 8:
TSP command reference
DMM7510-901-01 Rev. B / May 2015 8-283
Details
This attribute specifies which event causes a LAN trigger packet to be sent for this trigger. Set the
event to one of the existing trigger events, which are shown in the following table.
Setting this attribute to none disables automatic trigger generation.
If any events are detected before the trigger LAN connection is sent, the event is ignored and the
action overrun is set.
Trigger events
Event description Event constant
No trigger event
trigger.EVENT_NONE
Front-panel TRIGGER key press
trigger.EVENT_DISPLAY
Notify trigger block N (1 to 8) generates a trigger event when
the trigger model executes it
trigger.EVENT_NOTIFYN
A command interface trigger (bus trigger):
• Any remote interface: *TRG
• GPIB only: GET bus command
•
VXI-11: VXI-11 command device_trigger
trigger.EVENT_COMMAND
Line edge (either rising, falling, or either based on the
configuration of the line) detected on digital input line N
(1 to 6)
trigger.EVENT_DIGION
Line edge detected on TSP-Link synchronization line N
(1 to 3)
trigger.EVENT_TSPLINKN
Appropriate LXI trigger packet is received on LAN trigger
object N (1 to 8)
trigger.EVENT_LANN
Trigger event blender N (1 to 2), which combines trigger
events
trigger.EVENT_BLENDERN
Trigger timer N (1 to 4) expired
trigger.EVENT_TIMERN
Analog trigger
trigger.EVENT_ANALOGTRIGGER
External in trigger
trigger.EVENT_EXTERNAL
Example
trigger.lanout[5].stimulus = trigger.EVENT_TIMER1
Use the timer 1 trigger event as
the source for LAN trigger 5
stimulus.
Also see
trigger.lanout[N].connect() (on page 8-278)
trigger.lanout[N].ipaddress (on page 8-280)

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
