Ramp Down Dimmer (object number 4):
Dimmer snaps to 0% and fades slowly to 100%.
Figure 8: Ramp down dimmer effect
Dim/P/T Ballyhoo (object number 8):
Soft dimmer effect and pan tilt movement.
This effect is in the position effects as well.
Figure 9: Dim/P/T Ballyoo
Dim/Tilt Flyout (object number 9):
Fixtures are moving from position one to position two.
After they reached position two, dimmer fades to 0% and the fixtures moves back to position one.
Figure 10: Dim/Tilt Flyout
Position Effects
In the dot2 are eight predefined position effects available.
Circle (object number 5):
Fixtures moving in a circle.
Pan Sinus (object number 6):
Soft pan effect. Pan of the fixture moves around the current position, for example beginning from the current
position 0 the pan moves from - 15 till 15.
Tilt Sinus (object number 7)
Soft tilt effect. Tilt of the fixture moves around the current position, for example beginning from the current
position 0 the tilt moves from - 15 till 15.
