Command Guide of WGSW-28040
178
State: Disabled
Timer: 10 Seconds
Hold multiplier: 4
Reinit delay: 2 Seconds
Tx delay: 10 Seconds
LLDP packet handling: Flooding
4.13.6 lldp tlv-select
Command:
lldp tlv-select TLV [TLV] [TLV] [TLV] [TLV] [TLV] [TLV] [TLV]
no lldp tlv-select
Parameter:
TLV
Specify the selected optional TLV. Available optional TLVs are : sys-name (system
name), sys-desc (system description), sys-cap (system capability), mac-phy (802.3
MAC-PHY), lag (802.3 link aggregation), max-frame-size (802.3 max frame size), and
management-addr (management address).
Mode:
Interface Configuration
Usage Guide:
This command per port configures the selected TLV attaching in PDU. The “no lldp tlv-select” command would
remove all selected TLV. The configuration could be shown by “show lldp” command.
Example:
This example selects system name, system description, system capability, 802.3 MAC-PHY, 802.3 link aggregation,
802.3 max frame size, and management address TLVs for interface gi1 and gi3.
Switch(config)# interface range gi 1,3
Switch(config-if-range)# lldp tlv-select port-desc sys-name sys-desc sys-cap mac-phy
lag max-frame-size management-addr
Switch(config-if-range)# exit
Switch(config)# show lldp interfaces gi1,3
State: Disabled
Timer: 10 Seconds
