Command Guide of WGSW-28040
181
VLAN-LIST
Specify VLAN list. The configured ports should be member of all the specified VLANs or
the VLAN-LIST is not valid.
Mode:
Interface Configuration
Usage Guide:
The commands per port configure to add or remove VLAN list for 802.1 VLAN-NAME TLV. The configuration could be
shown by “show lldp” command.
Example:
This example add VLAN 1, 100, 4000 to VLAN-NAME TLV for port gi10.
Switch(config)# vlan 100
Switch(config-vlan)# exit
Switch(config)# vlan 4000
Switch(config-vlan)# exit
Switch(config)# interface gi10
Switch(config-if-range)# switchport trunk allowed vlan add all
Switch(config-if-range)# lldp tlv-select pvid enable
Switch(config-if-range)# exit
Switch(config)# show lldp interfaces gi1,gi2
State: Disabled
Timer: 10 Seconds
Hold multiplier: 3
Reinit delay: 2 Seconds
Tx delay: 2 Seconds
LLDP packet handling: Flooding
Port | State | Optional TLVs | Address
-------- + ------ + -------------- + --------
gi1 | RX,TX | |192.168.1.254
gi2 | RX,TX | |192.168.1.254
Port ID: gi1
802.3 optional TLVs:
802.1 optional TLVs
PVID: Disabled
Port ID: gi2
802.3 optional TLVs:
802.1 optional TLVs
PVID: Enabled
