Command Guide of WGSW-28040
183
lldp rx
no lldp rx
lldp tx
no lldp tx
Mode:
Interface Configuration
Usage Guide:
The command per port configures the LLDP PDU RX and TX ability. The configuration could be shown by “show lldp”
command.
Example:
This example sets port gi1 to enable LLDP RX and TX, port gi2 to disable RX but enable TX, port gi3 to enable RX
but disable TX, port gi4 to disable RX and TX.
Switch(config)# interface gi1
Switch(config-if)# lldp rx
Switch(config-if)# lldp tx
Switch(config-if)# exit
Switch(config)# interface gi2
Switch(config-if)# no lldp rx
Switch(config-if)# lldp tx
Switch(config-if)# exit
Switch(config)# interface gi3
Switch(config-if)# lldp rx
Switch(config-if)# no lldp tx
Switch(config-if)# exit
Switch(config)# interface gi4
Switch(config-if)# no lldp rx
Switch(config-if)# no lldp tx
Switch(config-if)# exit
Switch(config)# show lldp interfaces gi1-4
State: Enabled
Timer: 30 Seconds
Hold multiplier: 4
Reinit delay: 2 Seconds
