Command Guide of WGSW-28040
303
spanning-tree mode ( stp | rstp | mstp )
Parameter:
stp
Specify the mode to Spanning Tree Protocol
rstp
Specify the mode to Rapid Spanning Tree Protocol
mstp
Specify the mode to Multiple Spanning Tree Protocol.
Default:
spanning-tree mode stp
Mode:
Global Configuration
Usage Guide:
Configure the force-version of Spanning-Tree Protocol. The configuration could be shown by “show spanning-tree”
command.
Example:
This example sets STP mode to STP (Classic Spanning Tree Protocol).
Switch# configure
Switch(config)# spanning-tree mode stp
Switch(config)# exit
Switch# show spanning-tree
Spanning tree enabled mode STP
Default port cost method: long
Root ID Priority 32768
Address 00:30:4F:28:55:00
This switch is the root
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
Number of topology changes 1 last change occurred 00:05:13 ago
Times: hold 0, topology change 0, notification 0
hello 2, max age 20, forward delay 15
Interfaces
Name State Prio.Nbr Cost Sts Role EdgePort Type
--------- -------- -------- -------- ------ ---- -------- -----------------
gi1 enabled 128.1 200000 Dscd Desg No P2P (STP)
Switch#
