Ricoh Aficio MP C3501 Service Manual

System SP1-xxx
D086/D087 3-30 SM Appendix
160 Pressure:Thin:Low Speed *ENG
[0 to 3 / 3 / 1 /step]
161
Pressure:Thick4 *ENG
[0 to 3 / 3 / 1 /step]
Sets the default pressure position of the fusing unit for thick 4 paper.
0: Depression position (no pressure)
1: Position 1 (less pressure)
2: Position 2
3: Position 3 (strongest pressure)
201
Filler Edge Detection Counter ENG [0 to 9,000,000 / - / 1 /step]
Displays the detection time for the edge of the pressure roller actuator.
1152 [Fusing Nip Band Check]
001 Execute -
[0 or 1 / 0 / 1]
Executes the nip band measurement between heating roller and pressure roller.
If the nip band width is not 8 mm, and fusing is not good, replace the pressure
roller or install a new fusing unit.
002
Pre-Idling Time *ENG
[0 to 255 / 240 / 1 sec/step]
Specifies the fusing rotation time before executing SP1109-001.
003
Stop Time * ENG
[5 to 30 / 20 / 1 sec/step]
Specifies the time for measuring the nip.
004
Pressure Position * ENG
[1 to 3 / 3 / 1 ]
Specifies the pressure position for measuring the nip.

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
