Ricoh Aficio MP C3501 Service Manual

System SP2-xxx
D086/D087 3-52 SM Appendix
2112
[TM/ID Sensor Check] ID Sensor Check FA
001 Execute
This SP is used to check the ID sensors at
the factory. The results of this SP are
displayed in SP2140 to SP2145.
2117
[Skew Adjustment]
Specifies a skew adjustment value for the skew motor M, C or Y.
These SPs must be used when a new laser optics housing unit is installed or
when SC285 occurs. For details, see "Laser Optics Housing Unit" in the
"Replacement and Adjustment" section.
001 Pulse: M *ENG
[–100 to 100 / 0 / 1 pulse/step]
002 Pulse: C *ENG
003 Pulse: Y *ENG
2118 [Skew Adjustment]
001 Execute: M *ENG Changes the current skew adjustment
values to the values specified with SP2117.
These SPs must be used when a new laser
optics housing unit is installed or when
SC285 occurs. For details, see "Laser
Optics Housing Unit" in the "Replacement
and Adjustment" section.
002 Execute: C *ENG
003 Execute: Y *ENG

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
