System SP2-xxx
SM Appendix 3-53 D086/D087
Appendix:
SP Mode
Tables
2119
[Skew Adjustment Display]
Displays the current skew adjustment value for each skew motor.
001 M *ENG
[–50 to 50 / 0 / 1 pulse/step]
002 C *ENG
003 Y *ENG
2120
[Thick Paper Skew Adj] Not used
Selects the skew adjustment for thick paper.
001 On/Off *ENG
[0 or 1 / 1 / 1 /step]
0: Off, 1: On
2140
[ID Sensor Check Result] DFU
Displays the results of the ID sensor check.
Bk, M, C, Y: ID sensors for the process control
Front, Center, Rear: ID sensors for the automatic line position adjustment
001 Bk *ENG
[0 to 1024 / 0 / 1/step]
002 M *ENG
003 C *ENG
004 Y *ENG
005 Front *ENG
006 Center *ENG
007 Rear *ENG
2141
[ID Sensor Check Result: Ave.] DFU
Displays the average result values of the ID sensor check.
Bk, M, C, Y: ID sensors for the process control
Front, Center, Rear: ID sensors for the automatic line position adjustment
