System SP2-xxx
D086/D087 3-54 SM Appendix
001 Bk *ENG
[0 to 5.5 / 0 / 0.01V/step]
002 M *ENG
003 C *ENG
004 Y *ENG
005 Front *ENG
006 Center *ENG
007 Rear *ENG
2142
[ID Sensor Check Result] DFU
Displays the maximum result values of the ID sensor check.
Bk, M, C, Y: ID sensors for the process control
Front, Center, Rear: ID sensors for the automatic line position adjustment
001 Maximum: Bk *ENG
[0 to 5.5 / 0 / 0.01V/step]
002 Maximum: M *ENG
003 Maximum: C *ENG
004 Maximum: Y *ENG
005 Maximum: Front *ENG
006 Maximum: Center *ENG
007 Maximum: Rear *ENG
