System SP2-xxx
SM Appendix 3-55 D086/D087
Appendix:
SP Mode
Tables
2143
[ID Sensor Check Result] DFU
Displays the minimum result values of the ID sensor check.
Bk, M, C, Y: ID sensors for the process control
Front, Center, Rear: ID sensors for the automatic line position adjustment
001 Minimum: Bk *ENG
[0 to 5.5 / 0 / 0.01V/step]
002 Minimum: M *ENG
003 Minimum: C *ENG
004 Minimum: Y *ENG
005 Minimum: Front *ENG
006 Minimum: Center *ENG
007 Minimum: Rear *ENG
2144
[ID Sensor Check Result] DFU
Displays the maximum result 2 values of the ID sensor check.
Bk, M, C, Y: ID sensors for the process control
Front, Center, Rear: ID sensors for the automatic line position adjustment
001 Maximum 2: Bk *ENG
[0 to 5.5 / 0 / 0.01V/step]
002 Maximum 2: M *ENG
003 Maximum 2: C *ENG
004 Maximum 2: Y *ENG
005 Maximum 2: Front *ENG
006 Maximum 2: Center *ENG
007 Maximum 2: Rear *ENG
