Ricoh Aficio MP C3501 Service Manual

System SP2-xxx
D086/D087 3-56 SM Appendix
2145
[ID Sensor Check Result] DFU
Displays the minimum result 2 values of the ID sensor check.
Bk, M, C, Y: ID sensors for the process control
Front, Center, Rear: ID sensors for the automatic line position adjustment
001 Minimum 2: Bk *ENG
[0 to 5.5 / 0 / 0.01V/step]
002 Minimum 2: M *ENG
003 Minimum 2: C *ENG
004 Minimum 2: Y *ENG
005 Minimum 2: Front *ENG
006 Minimum 2: Center *ENG
007 Minimum 2: Rear *ENG
2150
[Area Mag. Correction] LD Pulse Area Correction (Color, Area) FA
Adjusts the magnification for each area. The main scan (297 mm) is divided
into 8 areas. Area 1 is at the front side of the machine (left side of the image)
and area 8 is at the rear side of the machine (right side of the image).
Decreasing a value makes the image shift to the left side on the print.
Increasing a value makes the image shift to the right side on the print.
1 pulse = 1/16 dot
027 Area 0: Bk *ENG
[-256 to 255 / 0 / 1sub-dot/step]
028 Area 1: Bk *ENG
Adjusts the area magnification for LD 0.
[–256 to 255 / 0 / 1 sub-dot/step ]
029 Area 2: Bk *ENG
030 Area 3: Bk *ENG
031 Area 4: Bk *ENG
032 Area 5: Bk *ENG
033 Area 6: Bk *ENG
034 Area 7: Bk *ENG

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
