Ricoh Aficio MP C3501 Service Manual

System SP2-xxx
SM Appendix 3-65 D086/D087
Appendix:
SP Mode
Tables
041 M. Scan Erro.: Left: Y *ENG
042 M. Scan Erro.: Center: Y *ENG
043 M. Scan Erro.: Right: Y *ENG
044 S. Scan Erro.: Left: Y *ENG
045 S. Scan Erro.: Center: Y *ENG
046 S. Scan Erro.: Right: Y *ENG
047 M. Cor.: Dot: Y *ENG
[–512 to 511 / 0 / 1 dot/step]
048 M. Cor.: Subdot: Y *ENG
[–15 to 15 / 0 / 1 pulse/step]
049 Paper Int. Mag: Subdot: Y *ENG
[–32768 to 32767 / 0 / 1 pulse/step]
050 Mag.Cor. Subdot: Y *ENG
051 M. Left Mag.: Subdot: Y *ENG
052 M. Right Mag.: Subdot: Y *ENG
053 S. Cor.: 600 Line: Y *ENG
[–16384 to 16383 / 0 / 1 line/step]
054 S. Cor.: 600 Sub: Y *ENG
[–1 to 1 / 0 / 0.001 line/step]
055 S. Cor.: 1200 Line: Y *ENG
[–16384 to 16383 / 0 / 1 line/step]
056 S. Cor.: 1200 Sub: Y *ENG
[–1 to 1 / 0 / 0.001 line/step]
2182
[Line Position Adj. Offset]
(Color) M. Scan: Main scan, S. Scan: Sub-scan
High: 154 mm/sec, Medium: 111 mm/sec, Low: 77 mm/sec
001 M Magnification *ENG Adjusts the line position manually.
[-1 to 1 / 0 / 0.001%/step]
When line shifts are not corrected
by the automatic line position
adjustment, do this SP.
Increasing a value reduces the
image in the main scan direction.
Decreasing a value enlarges the
002 C Magnification *ENG
003 Y Magnification *ENG
