Ricoh Aficio MP C3501 Service Manual

System SP2-xxx
D086/D087 3-66 SM Appendix
image in the main scan direction.
004 M. Scan: High: Dot: M *ENG
[-512 to 511 / 0 / 1 dot/step]
005 M. Scan: High: Subdot: M *ENG
[-15 to 15 / 0 / 1 pulse/step]
006 M. Scan: Medium: Dot: M *ENG
[-512 to 511 / 0 / 1 dot/step]
007 M. Scan: Medium: Subdot: M *ENG
[-15 to 15 / 0 / 1 pulse/step]
008 M. Scan: Low: Dot: M *ENG
[-512 to 511 / 0 / 1 dot/step]
009 M. Scan: Low: Subdot: M *ENG
[-15 to 15 / 0 / 1 pulse/step]
010 M. Scan: High: Dot: C *ENG
[-512 to 511 / 0 / 1 dot/step]
011 M. Scan: High: Subdot: C *ENG
[-15 to 15 / 0 / 1 pulse/step]
012 M. Scan: Medium: Dot: C *ENG
[-512 to 511 / 0 / 1 dot/step]
013 M. Scan: Medium: Subdot: C *ENG
[-15 to 15 / 0 / 1 pulse/step]
014 M. Scan: Low: Dot: C *ENG
[-512 to 511 / 0 / 1 dot/step]
015 M. Scan: Low: Subdot: C *ENG
[-15 to 15 / 0 / 1 pulse/step]
016 M. Scan: High: Dot: Y *ENG
[-512 to 511 / 0 / 1 dot/step]
017 M. Scan: High: Subdot: Y *ENG
[-15 to 15 / 0 / 1 pulse/step]
018 M. Scan: Medium: Dot: Y *ENG
[-512 to 511 / 0 / 1 dot/step]
019 M. Scan: Medium: Subdot: Y *ENG
[-15 to 15 / 0 / 1 pulse/step]
020 M. Scan: Low: Dot: Y *ENG
[-512 to 511 / 0 / 1 dot/step]
021 M. Scan: Low: Subdot: Y *ENG
[-15 to 15 / 0 / 1 pulse/step]
022 S. Scan: High: Line: M *ENG
[-16384 to 16383 / 0 / 1 line/step]
023 S. Scan: High: Subline: M *ENG
[–1 to 1 / 0 / 0.001 /line]

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
