Booklet Finisher SR3000 (B793)
SM 2-71 D086/D087
Installation
2. Open the front door [A] of the 1000-sheet booklet finisher, and then pull out the jogger
unit [B].
3. Remove all tapes and packing materials from the inside of the finisher.
4. Attach the cushions [C] to the finisher.
Make sure that the cushions are placed within 0 to 1 mm [D] from the edge of the
cover or frame.
5. Install the ground plate [E] on the finisher (
x 2; M3 x 8).
To Next Page
