Input and Output Check
D086/D087 3-404 SM Appendix
Table 1: Paper Height Sensor
0: Deactivated, 1: Activated (actuator inside sensor)
Remaining paper Paper height sensor 1 Paper height sensor 2
Full 0 0
Nearly full 1 0
Near end 1 1
Almost empty 0 1
