Input and Output Check
D086/D087 3-408 SM Appendix
6138 Description
Reading
0 1
(Bottom Tray HP 1 Sensor)
6138 11
Folder Tray Full Sensor 2
(Bottom Tray HP 2 Sensor)
Not full Full
6138 12
Folder Plate HP Sensor
(Fold Plate HP Sensor)
Not home position Home position
6138 13
Saddle Stitch Arrival Sensor
(Fold Unit Entrance Sensor)
Paper not
detected
Paper detected
6138 14
Folder Cam HP Sensor
(Fold Plate Cam HP Sensor)
Not home position Home position
6138 15
Staple Exit Sensor
(Stapler Tray Exit Sensor)
Paper detected
Paper not
detected
6138 16
Shift Tray Paper Sensor
(Shift Tray Paper Position Sensor)
Shift tray not
detected
Shift tray
detected
6138 17 Shift Tray Full Full Nor full
6138 18 Shift Roller HP Sensor Not home position Home position
6138 20
Entrance Sensor
(Finisher Entrance Sensor)
Paper detected
Paper not
detected
6138 21
Shift Exit Sensor
(Shift Tray Exit Sensor)
Paper not
detected
Paper detected
6138 22
Proof Exit Sensor
(Proof Tray Exit Sensor)
Paper detected
Paper not
detected
6138 23 Exit Guide Plate HP Sensor Not home position Home position
6138 24
Proof Full Sensor
(Proof Tray Full Sensor)
Not full Full
6138 25 Upper Cover Sensor Open Close
6138 26
Door SW
(Front Door Switch)
Close Open
