Input and Output Check
SM Appendix 3-407 D086/D087
Appendix:
SP Mode
Tables
6007 14 Exit Sensor
Paper not
detected
Paper detected
6007 15 Feed Cover ADF cover close ADF cover open
6007 16 Lift Up ADF cover close ADF cover open
1000-Sheet Booklet Finisher (B793)
6138 Description
Reading
0 1
6138 1
Interference Escape Sensor
(Stapler Safety Sensor)
Not interfered Interfered
6138 2
Staple Moving HP Sensor
(Staple Unit HP Sensor)
Not home position Home position
6138 3
Stuck Relay1 Release HP Sensor
(Stopper S HP Sensor)
Not home position Home position
6138 4
Exit Junction Gate HP Sensor
(Stack Feed Out HP Sensor)
Home position
Not home
position
6138 5
Jogger HP Sensor
(Jogger Fence HP Sensor)
Not home position Home position
6138 6
Staple Tray Paper Sensor
(Staple Tray Paper Sensor)
Paper not
detected
Paper detected
6138 7
Rear Edge Fence HP Sensor
(Paper Stack Stopper HP Sensor)
Not home position Home position
6138 8 Saddle Stitch Exit Sensor Paper detected
Paper not
detected
6138 9
Stuck Relay2 Roller HP Sensor
(Clamp Roller HP Sensor)
Home position
Not home
position
6138 10 Folder Tray Full Sensor 1 Full Not full
