Input and Output Check
D086/D087 3-406 SM Appendix
ADF (D541)
6007 Description
Reading
0 1
6007 1
Original Length 1 (B5 Detection
Sensor)
Paper not
detected
Paper detected
6007 2
Original Length 2 (A4 Detection
Sensor)
Paper not
detected
Paper detected
6007 3
Original Length 3 (LG Detection
Sensor)
Paper not
detected
Paper detected
6007 4 Original Width S
Paper not
detected
Paper detected
6007 5 Original Width M
Paper not
detected
Paper detected
6007 6 Original Width L
Paper not
detected
Paper detected
6007 7 Original Width LL
Paper not
detected
Paper detected
6007 9 Original Detection
Paper not
detected
Paper detected
6007 10 Rear Edge Detection
Paper not
detected
Paper detected
6007 11 Skew Correction
Paper not
detected
Paper detected
6007 13 Registration Sensor
Paper not
detected
Paper detected
