Input and Output Check
D086/D087 3-414 SM Appendix
1 Bin Tray (D536)
6154 Description
Reading
0 1
6154 1 1 bin: Set Sensor Set Not Set
6154 2 1 bin: Paper Sensor Paper detected
Paper not
detected
One or Two-Tray PFU (D387/D537)/ LCIT 2000 (D538)/ LCIT 1200 (D539)
6160 Description
Reading
0 1
6160 1 Bank: Tray3: Feed Sensor
Paper not
detected
Paper detected
6160 2 Bank: Tray4: Feed Sensor
Paper not
detected
Paper detected
6160 3 Bank: Tray5: Feed Sensor
Paper not
detected
Paper detected
6160 4 Bank: Tray3: Relay Sensor
Paper not
detected
Paper detected
6160 5 Bank: Tray4: Relay Sensor
Paper not
detected
Paper detected
6160 6 Bank: Tray5: Relay Sensor
Paper not
detected
Paper detected
6160 7 Bank: Feed Cover Detection Closed Open
6160 11 Bank: Palau: Paper Supply Switch Closed Open
6160 12 Bank: Palau: Slide Switch Closed Open
