Ricoh Aficio MP C3501 - Page 1395

Input and Output Check
SM Appendix 3-415 D086/D087
Appendix:
SP Mode
Tables
3.9.2 OUTPUT CHECK TABLE
Copier
5804 Display Description
5804 3 Drum/Dev Motor: K: HighSpeed
Drum/Development Drive Motor-K:
HighSpeed
5804 4 Drum/Dev Motor: K: MiddleSpeed
Drum/Development Drive Motor-K:
Middle Speed
5804 5 Drum/Dev Motor: K: LowSpeed
Drum/Development Drive Motor-M: Low
Speed
5804 10 Drum/Dev Motor: M: HighSpeed
Drum/Development Drive Motor- C:
HighSpeed
5804 11
Drum/Dev Motor: M:
MiddleSpeed
Drum/Development Drive Motor-Y:
Middle Speed
5804 12 Drum/Dev Motor: M: LowSpeed
Drum/Development Drive Motor-Y: Low
Speed
5804 17 Drum/Dev Motor: C: HighSpeed
Drum/Development Drive Motor- C:
HighSpeed
5804 18
Drum/Dev Motor: C:
MiddleSpeed
Drum/Development Drive Motor-Y:
Middle Speed
5804 19 Drum/Dev Motor: C: LowSpeed
Drum/Development Drive Motor-Y: Low
Speed
5804 24 Drum/Dev Motor: Y: HighSpeed
Drum/Development Drive Motor- C:
HighSpeed
