Input and Output Check
D086/D087 3-416 SM Appendix
5804 25 Drum/Dev Motor: Y: MiddleSpeed
Drum/Development Drive Motor-Y:
Middle Speed
5804 26 Drum/Dev Motor: Y: LowSpeed
Drum/Development Drive Motor-Y: Low
Speed
5804 31 Fusing Exit Motor: HighSpeed Fusing/Paper Exit Motor: HighSpeed
5804 32 Fusing Exit Motor: MiddleSpeed Fusing/Paper Exit Motor: Middle Speed
5804 33 Fusing Exit Motor: LowSpeed Fusing/Paper Exit Motor: Low Speed
5804 35 Fusing Exit Motor: LLowSpeed Fusing/Paper Exit Motor: LLowSpeed
5804 37 Toner Relay Motor Toner Transport Motor
5804 40
Image Transfer Motor:
HighSpeed
ITB Drive Motor: HighSpeed
5804 41
Image Transfer Motor:
MiddleSpeed
ITB Drive Motor: Middle Speed
5804 42 Image Transfer Motor: LowSpeed ITB Drive Motor: Low Speed
5804 50 Feed Motor: HighSpeed Paper Feed Motor: High Speed
5804 51 Feed Motor: IncreaseSpeed Paper Feed Motor: Increase Speed
5804 52 Feed Motor: MiddleSpeed Paper Feed Motor: Middle Speed
5804 53
Feed Motor:
MiddleIncreaseSpeed
Paper Feed Motor: Middle Increase
Speed
5804 54 Feed Motor: LowSpeed Paper Feed Motor: Low Speed
5804 55 Feed Motor: LowInceraseSpeed Paper Feed Motor: Low Incerase Speed
5804 60 Regist Motor: HighSpeed Registration Motor: High Speed
5804 61 Regist Motor: MiddleSpeed Registration Motor: Middle Speed
