Ricoh Aficio MP C3501 - Page 1397

Input and Output Check
SM Appendix 3-417 D086/D087
Appendix:
SP Mode
Tables
5804 62 Regist Motor: LowSpeed Registration Motor: Low Speed
5804 67 Duplex Feed M:CW:HighSpeed Duplex/By-pass Motor: CW: High Speed
5804 68 Duplex Feed M:CW:MiddleSpeed
Duplex/By-pass Motor: CW: Middle
Speed
5804 69
Duplex Feed Motor: CW:
LowSpeed
Duplex/By-pass Motor: CW: Low Speed
5804 74 Duplex Feed M:CCW:HighSpeed
Duplex/By-pass Motor: CCW:
High Speed
5804 75
Duplex Feed
M:CCW:MiddleSpeed
Duplex/By-pass Motor: CCW:
Middle Speed
5804 76
Duplex Feed Motor: CCW:
LowSpeed
Duplex/By-pass Motor: CCW:
Low Speed
5804 81
Duplex Reverse
M:CW:HighSpeed
Duplex Inverter Motor: CW: High Speed
5804 82
Duplex Reverse
M:CW:MiddleSpeed
Duplex Inverter Motor: CW: Middle Speed
5804 83
Duplex Reverse Motor: CW:
LowSpeed
Duplex Inverter Motor: CW: Low Speed
5804 88
Duplex Reverse
M:CCW:HighSpeed
Duplex Inverter Motor: CCW:
High Speed
5804 89
Duplex Reverse
M:CCW:MiddleSpeed
Duplex Inverter Motor: CCW:
Middle Speed
5804 90
Duplex Reverse Motor: CCW:
LowSpeed
Duplex Inverter Motor: CCW:
Low Speed
5804 95 ITB Contact Motor Image Transfer Belt Contact Motor
