Input and Output Check
D086/D087 3-418 SM Appendix
5804 96 Paper Transfer Contact Motor Paper Transfer Contact Motor
5804 97 1st Tray Lift Motor: Up Tray Lift Motor 1: Lift Up
5804 98 1st Tray Lift Motor: Down Tray Lift Motor 1: Lift Down
5804 99 2nd Tray Lift Motor: Up Tray Lift Motor 2: Lift Up
5804 100 2nd Tray Lift Motor: Down Tray Lift Motor 2: Lift Down
5804 102 Fusing Pressue Release Motor Pressure Roller Contact Motor
5804 104 Polygon Moter: LL Polygon Motor: LL
5804 105 Polygon Moter: L Polygon Motor: L
5804 107 Polygon Moter: HH Polygon Motor: HH
5804 110 Air Flow Fan: Front Ventilation Fan – Front
5804 111 Air Flow Fan:Rear Ventilation Fan – Rear
5804 112 Fusing Fan:H Fusing Fan: High Speed
5804 113 Fusing Fan:L Fusing Fan: Low Speed
5804 114 PSU Cooling Fan PSU Fan 1: High Speed
5804 115 2nd Duct Fan: H Duct Fan 2: High Speed
5804 117 3rd Duct Fan: H Duct Fan 3: High Speed
5804 119 Paper Exit Fan:H Paper Exit Fan: High Speed
5804 121 Fusing Coil Fan IH Coil Fan
5804 122 IH Power Supply Cooling Fan IH Inverter Fan
5804 126 Development Clutch: Bk Development Clutch-K
5804 127 Development Clutch: M Development Clutch-M
