Ricoh Aficio MP C3501 Service Manual

Input and Output Check
SM Appendix 3-419 D086/D087
Appendix:
SP Mode
Tables
5804 128 Development Clutch: C Development Clutch-C
5804 129 Development Clutch: Y Development Clutch-Y
5804 130 Toner Bottle Clutch: Bk Toner Bottle Clutch-K
5804 131 Toner Bottle Clutch: M Toner Bottle Clutch-M
5804 132 Toner Bottle Clutch: C Toner Bottle Clutch-C
5804 133 Toner Bottle Clutch:Y Toner Bottle Clutch-Y
5804 134 Toner Supply Pump: Bk Toner Supply Clutch: Bk
5804 135 Toner Supply Pump: M Toner Supply Clutch: M
5804 136 Toner Supply Pump: C Toner Supply Clutch: C
5804 137 Toner Supply Pump: Y Toner Supply Clutch: Y
5804 138 1st Paper Feed Clutch Paper Feed Clutch 1
5804 139 2nd Paper Feed Clutch Paper Feed Clutch 2
5804 140 Bypass Feed Clutch By-pass Feed Clutch
5804 141 Bypass Pickup Solenoid Bypass Pickup Solenoid
5804 143 TD Sensor Shutter Solenoid ID Sensor Shutter Solenoid
5804 144 Exit Junction Solenoid Junction Gate 1 Solenoid
5804 145 1st Feed Pickup Solenoid 1st Pickup Solenoid
5804 146 2nd Feed Pickup Solenoid 2nd Pickup Solenoid
5804 150 Duplex Fan: HighSpeed
5804 151 Duplex Fan: LowSpeed
5804 152 Air Flow Fan: Middle 1

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
