Ricoh Aficio MP C3501 Service Manual

Input and Output Check
SM Appendix 3-423 D086/D087
Appendix:
SP Mode
Tables
ARDF (D541)
6008 Display Description
6008 3 Feed Motor Forward Feed Motor-Forward rotation
6008 4 Feed Motor Reverse Feed Motor-Reverse rotation
6008 5 Relay Motor Forward Transport Motor- Forward rotation
6008 6 Relay Motor Reverse Transport Motor- Forward rotation
6008 9 Feed Clutch -
6008 10 Feed Solenoid Pick-up Solenoid
6008 11 Inverter Solenoid -
6008 12 Stamp Stamp Solenoid
1000-Sheet Booklet Finisher (B793)
6143 Display Description
6143 1 Shift Motor Shift Tray Motor
6143 2 Entrance Motor -
6143 3 Staple Relay Motor Stapler Unit Motor
6143 4 Knock Solenoid
6143 5 Junction Gate SOL 1 Proof Tray Gate Solenoid
6143 6 Junction Gate SOL 2 Staple Tray Gate Solenoid
6143 7 Folder Roller Rotation Motor Fold Roller Motor
6143 8 Staple Motor Staple Fold Motor
6143 10 Exit Guide Plate Motor -
6143 11 Shift Relay Motor Upper Transport Motor

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
