Ricoh Aficio MP C3501 Service Manual

Input and Output Check
D086/D087 3-424 SM Appendix
6143 12 Tray Motor Shift Tray Motor
6143 13 Stack Feed-out Motor Positioning Roller Solenoid
6143 14 Stuck Relay1 Motor Upper Clamp Roller Motor
6143 15 Stuck Relay1 Release Motor Upper Retraction Motor
6143 16 Rear Edge Fence Drive Motor Bottom Fence Lift Motor
6143 17 Folder Plate Motor -
6143 18 Drive Roller Oscillating Motor Lower Retraction Motor
6143 19 Staple Moving Motor Staple Unit Driver Motor
6143 20 Jogger Motor Jogger Motor
6143 21
Punch Registration Moving
Motor
Paper Position Sensor Slide Motor
6143 22 Punch Motor -
6143 23 Punch Moving Motor Punch Movement Motor

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
