Ricoh Aficio MP C3501 Service Manual

Input and Output Check
D086/D087 3-426 SM Appendix
500-Sheet Finisher (D372)
6146 Display Description
6146 1 Carry Motor Transport Motor
6146 2 Hitroll Motor Positioning Roller Arm Motor
6146 3 Front Jogger Motor Front Fence Motor
6146 4 Rear Jogger Motor Rear Fence Motor
6146 5 Staple Moving Motor Stapler Movement Motor
6146 6 Stack Feed-out Motor Feed-Out Belt Motor
6146 7 Tray Motor Tray Lift Motor
6146 8 Staple Motor Stapler Motor
6146 9 Stopper Solenoid Stack Depressor Solenoid
Bridge Unit (D386)/ Side Tray (D542)
6151 Display Description
6151 1
Bridge/Left: Feed Motor: Current
Selection
Bridge: Feed Motor: Current switching
signal
6151 2 Bridge/Left: Feed Motor:Reset Bridge: Feed Motor:Reset
6151 3 Bridge/Left: Feed Motor:Enable Bridge: Feed Motor:Enable
6151 6
Bridge/Left: Feed Motor: High
Speed
Bridge: Feed Motor: High Speed
6151 7
Bridge/Left: Feed Motor: Middle
Speed
Bridge: Feed Motor: Middle Speed
6151 8
Bridge/Left: Feed Motor: Low
Speed
Bridge: Feed Motor: Low Speed
6151 11 Bridge/Left: Junction Solenoid Bridge: Junction Solenoid

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
