Ricoh Aficio MP C3501 Service Manual

Input and Output Check
SM Appendix 3-427 D086/D087
Appendix:
SP Mode
Tables
Shift Tray (D388)
6153 Display Description
6153 1 Shift: Lift-up Motor -
1 Bin Tray (D414)
6155 Display Description
6155 1 1 bin: Junction Solenoid -
One or Two-Tray PFU (D387/D537)/ LCIT 2000 (D538)/ LCIT 1200 (D539)
6161 Display Description
6161 7 Bank1: Feed Motor:242mm/s
Feed Motor:242mm/s
(D537/ D538)
6161 17 Bank2: Feed Motor:242mm/s Feed Motor:242mm/s (D539)
6161 21 Bank2: Feed Motor:154mm/s Feed Motor:154mm/s (D539)
6161 30 Bank:Tray3: PU Solenoid Pick-up Solenoid (D537/D538 or D387)
6161 31 Bank:Tray4: PU Solenoid Pick-up Solenoid (D537/D539)
6161 32 Bank:Tray5: PU Solenoid Pick-up Solenoid (D539)
6161 35 Bank:Tray3: Feed Clutch Pick-up Solenoid (D537/D538 or D387)
6161 36 Bank:Tray4: Feed Clutch Pick-up Solenoid (D537/D539)
6161 37 Bank:Tray5: Feed Clutch Pick-up Solenoid (D539)

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
