Printer Service Mode
D086/D087 3-428 SM Appendix
3.10 PRINTER SERVICE MODE
3.10.1 SP1-XXX (SERVICE MODE)
1001 Bit Switch
001 Bit Switch 1 0 1
bit 0 DFU - -
bit 1 DFU - -
bit 2 DFU - -
bit 3
No I/O Timeout
0: Disable 1: Enable
Enable: The MFP I/O Timeout setting will have no effect. I/O Timeouts will
never occur.
bit 4
SD Card Save Mode
0: Disable 1: Enable
Enable: Print jobs will be saved to an SD Card in the GW SD slot ( "Card
Save Function" in the System Maintenance Reference of the Field Service
Manual).
bit 5 DFU - -
bit 6 DFU - -
bit 7
[RPCS,PCL]: Printable area frame border
0: Disable 1: Enable
Enable: The machine prints all RPCS and PCL jobs with a border on the
edges of the printable area.
