Ricoh Aficio MP C3501 Service Manual

Printer Service Mode
D086/D087 3-430 SM Appendix
bit 3 DFU - -
bit 4 DFU - -
bit 5 DFU - -
bit 6 DFU - -
bit 7 DFU - -
1001 Bit Switch
004
Bit Switch 4 DFU
- -
1001 Bit Switch
005 Bit Switch 5 0 1
bit 0
Show "Collate Type", "Staple Type" and
"Punch Type" buttons on the operation
panel.
Disable Enable
If enabled, users will be able to configure a Collate Type, Staple Type, and
Punch Type from the operation panel. The available types will depend on
the device and configured options.
After enabling the function, the settings will appear under:
"User Tools > Printer Features > System"
bit 1 DFU - -
bit 2 DFU - -
bit 3
[PS] PS Criteria
Pattern3 Pattern1
Change the number of PS criterion used by the PS interpreter to
determine whether a job is PS data or not.
Pattern3: includes most PS commands.
Pattern1: A small number of PS tags and headers
bit 4
Increase max number of the stored jobs
to 1000 jobs.
Disable
(100)
Enable (1000)
Enable: Changes the maximum number of jobs that can be stored on the

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
