Component Layout
SM 41 B793
B793
Booklet
Finisher
Item No. Purpose
Motor
Punch
Motor
48 Punches the holes in the paper.
Paper
Position
Sensor
Slide Motor
52
Controls side-to-side movement of the paper position sensor in the
punch unit.
Punch
Movement
Motor
57 Moves the punch from side to side.
Solenoids
Item No. Purpose
Proof Tray Gate Solenoid 13 Controls the proof tray junction gate
Positioning Roller Solenoid 16 Controls the positioning roller.
Staple Tray Gate Solenoid 21 Controls the staple tray junction gate
Switches
Item No. Purpose
Upper Limit
Switch
4
Detects when the shift tray is at the highest possible position,
and cuts power to the shift tray motor.
Front Door
Safety Switch
11 Cuts dc power when the front door is opened.
Others
Item No. Purpose
Staple Driver Unit 31 Pushes the staples into the paper.
Staple Folder Unit 32 Folds the ends of the staples after stapling
